DS-3WF01C-2N hikvision wireless
- Wireless
- StandardIEEE802.11 b/g/n(2T2R 300Mbps)
- Operation Frequency2412 to 2472 MHz(More Non-standard channels is availability,2312MHz to 2732MHz)
- AntennaInternal, 6dBi, H: 65° V: 60°
- Max Output Power27dBm
- Receive Sensitivity-72dBm@65Mbps, -97dBm@1Mbps
- Max Transmission Rate11n: 300Mbps(HT40)/130Mbps(HT20) 11g: 54Mbps
- Hardware
- Power Supply48V/0.25A PoE or 12 VDC
- Interface3×10/100M Base-TX (Cat. 5/5E, RJ-45) ports
- Operation Temperature-30℃ to +65℃(-22℉ to +149℉)
- Storage Temperature-40℃ to +85℃(-40℉ to +185℉)
- Operation Humidity5% to 95%RH non-condensing
- Dimensions150×150×31.6 mm (5.9×5.9×1.24 inch)
- Software
- Application ScenariosElevator Room/IP Camera
- EncryptionWPA-PSK/WPA2-PSK
- Network ModeRouter/Bridge
- SecurityIP/MAC filter, SSID hidden, Interface Isolation
- Network ProtocolTCP/UDP/ARP/ICMP/DHCP/HTTP/NTP
- TDMASupported (Extend private communication protocol)
- Auto ACK Timing AdjustSupported (It can automatically detect the distances of the devices, keep the performance always the best)
- Management And LogsNTP, Syslog, Telnet, AC
- Web Based ConfigurationSupported
- Firmware UpdateSupport update firmware by Web page
- Bandwidth20M/40MHz
-
DS-3E0524-E(B)hikvision switch
Specifications
- Network Parameters
- Port Number24 x 1000M Ethernet port
- Port TypeRJ45 port, Full duplex, MDI/MDI-X adaptive
- StandardIEEE 802.3, IEEE 802.3u, IEEE 802.3x
- Forwarding ModeStore-and-forward switching
- MAC Address Table8 K
- Switching Capacity48 Gbps
- Packet Forwarding Rate35.712 Mpps
- Internal Cache4.1 Mbits
- General
- ShellMetal material, fan-free design
- Net Weight1.6 kg (3.5 lb)
- Dimension (L × H × D)335 mm × 44.5 mm ×175.8 mm (13.2” × 1.8” × 6.9”)
- Operating Temperature0˚C to 40˚C (32˚F to 104˚F)
- Storage Temperature–40˚C to 85˚C (–40˚F to 185˚F)
- Storage Humidity5% to 95% (no condensation)
- Power Supply220 VAC， 50/60 Hz， Max. 0.7 A
-
DS-3E0516-E(B)-hikvision switch
- Network Parameters
- Port Number16 x 1000M Ethernet port
- Port TypeRJ45 port, Full duplex, MDI/MDI-X adaptive
- StandardIEEE 802.3, IEEE 802.3u, IEEE 802.3x
- Forwarding ModeStore-and-forward switching
- MAC Address Table8 K
- Switching Capacity32 Gbps
- Packet Forwarding Rate23.808 Mpps
- Internal Cache4.1 Mbits
- General
- ShellMetal material, fan-free design
- Net Weight1.2 kg (2.6 lb)
- Dimension (L × H × D)257 mm × 44.5 mm ×175.8 mm (10.1” × 1.8” × 6.9”)
- Operating Temperature0˚C to 40˚C (32˚F to 104˚F)
- Storage Temperature–40˚C to 85˚C (–40˚F to 185˚F)
- Storage Humidity5% to 95% (no condensation)
- Power Supply220 VAC，50/60 Hz，Max. 0.3 A
-
DS-3E1526P-E-hikvision switch
Specifications
General
Shell
Metal material
Operating Temperature
-10 °C to 55 °C (14 °F to 131 °F)
Storage Temperature
-40 °C to 85 °C (-40 °F to 185 °F)
Relative Humidity
5% to 95% (no condensation)
Power Supply
100 to 240 VAC, 50/60 Hz, Max. 6.5 A
Net Weight
2.975 kg (6.56 lb)
Gross Weight
3.535 kg (7.79 lb)
Dimension (L × H × D)
440 mm × 221 mm × 44 mm (17.32” × 8.70” × 1.73”)
Operating Humidity
5% to 95% (no condensation)
Power Source
400 W
Power Consumption In Idle
30 W
Max. Power Consumption
400 W -
DS-3E2528P-hikvision switch
Specification
DS-3E2510P
DS-3E2510P
Port Number
24 x 10/100/1000Base-T PoE ports, 4 1000Base-X SFP ports, 1 Console port
Switching Capacity
56Gbps
Packet Forwarding Rate
42Mpps
MAC Address Table
8K
Dimensions(L × H × D)
440 mm × 45 mm × 232 mm
Consumption
<15W
POE Standard
IEEE802.3af, IEEE802.3at
POE Power Budget
380W
Power Supply
AC：100V-240V，50Hz±10%
Environment
Operating temperature/humidity: 0℃-45℃，5%-95% non-condensing Storage temperature/humidity: -20℃-70℃；5%-95% non-condensing
MAC Exchange
Static configuration and dynamic MAC learning; MAC browsing and removal Configurable aging time of the MAC address; Limited number of learnable MAC -
Aruba Instant On 1930 24G Class4 PoE 4SFP/SFP+ 370W Switch
Aruba Instant On 1930 24G Class4 PoE 4SFP/SFP+ 370W Switch
Brand: Aruba a Hewlett Packard Enterprise company
Mounting Type: Surface Mount
International Protection Rating: IP40
Control Method: App, Voice
Wattage: 439 watts -
Dell Networking S4128F-ON Switch
Model: S4128F – Dell Networking S4100-ON Switches Detail: Dell Networking S4128F-ON, 1U, PHY-less, 28 x 10GbE SFP+, 2 xQSFP28, IO to PSU, 2 PSU, OS10, 3 years* 4h service -
Dell Networking S4048-ON Switch
Model: S4048-1NBD – Dell Networking S4048-ON Series Switches Detail: Dell Networking S4048-ON, 48x 10GbE SFP+ , 6x 40GbE QSFP+ , I/O Panel to PSU Airflow, 1x AC PSUs, DNOS9，1 year NBD -
Dell Networking N4032F Switch
Model: N4032F – Dell Networking N4000 Series Switches Detail: Dell Networking N4032F, 24x 10GbE SFP+ Port, 1x Modular bay, 2x AC PSU,airflow from IO to PSU -
Dell Networking N3024 Switch
N3024 Switch
Model: N3024 – Dell Networking N3000 Series Switches Detail: Dell Networking N3024, L3 ,24x1GbE, 2xCombo, 2x10GbE SFP+Fixed port, stack, airflow from IO to PSU, 1x AC PSU -
Dell Networking X1008/1008P Series Switch
Dell Networking X1008/1008P
Dell Networking X1008/1008P 10/100/1000Base-T auto-sensing Gigabit Ethernet switching ports: 8
SFP/SFP + fiber ports: not available
Power over Ethernet (PoE) ports: not available
PoE powered: standard
Power reduction for short cables or inactive connections: standard
Autonegotiation for speed, duplex mode and flow control: standard
Auto-MDI/MDIX mode and flow control: standard
