Cisco Catalyst 2960X-48FPS-L – switch – 48 ports – managed – rack-mountable Switch

In stock

Compare

Get the Cisco Catalyst 2960X-48FPS-L – switch – 48 ports – managed – rack-mountable Switch at the best price in Kenya from Wodex Technologies

Cisco Catalyst 2960X series 48 ports LAN Base stackable switch delivers Power over Ethernet Plus(PoE+) that supports up to 740W of PoE budget for 24 ports with 30W per port or 48 ports with 15.4W per port.

Quick Specs

Table 1 shows the Quick Specs.

Product Code WS-C2960X-48FPS-L
Enclosure Type Rack-mountable – 1U
Feature Set LAN Base
Uplink Interfaces 4 x 1G SFP
Ports 48 x 10/100/1000 Ethernet Gigabit ports
Available PoE Power 740W
Maximum stacking number 8
Stack bandwidth 80G
Forwarding Performance 107.1Mpps
Switching Bandwidth 216Gbps
RAM 512 MB
Flash Memory 128 MB
Dimensions 44.5 cm x 36.8 cm x 4.5 cm
Package Weight 10.65 Kg

Product Details

Figure 1 shows the front panel of the Cisco Catalyst 2960X-48FPS-L switch.

cisco ws-c2960x-48fps-l front panel

Note:

① Ethernet management port ② Mode button ③ Switch LEDs ④ USB mini-Type B (console) port ⑤ USB Type A ports

⑥ SFP module ports ⑦ 48 x 10/100/1000 ports ⑧ CONSOLE LED ⑨ MGMT LED ⑩ RJ-45 console port

·The Switch LEDs include SYST, STAT, SPEED, RPS, MAST, POE and STACK LEDs.

·Power over Ethernet Plus(PoE+) supports up to 740W of PoE budget for 24 ports with 30W per port or 48 ports with 15.4W per port.

Figure 2 shows the back panel of the Cisco Catalyst 2960X-48FPS-L switch.

cisco ws-c2960x-48fps-l back panel

Note:

① FlexStack-Plus module slot and cover ② Fan Exhaust  ③ RPS Connector ④ AC power connector

Figure 3 shows the stackable capacity.

This C2960X switch delivers stackable capacity that supports up to 8 switches stacking with same 2960-X LAN base series. It also can stack up to 4 switches stacking when mixed with 2960-S LAN base series switches.

Stackable Switches

Figure 4 shows WS-C2960X-48FPS-L and cables.

WS-C2960X-48FPS-L and cables
