Dell PowerEdge T640 3104
PowerEdge T640
Maximum performance and scalability
The Dell PowerEdge T640 delivers the ultimate two-socket performance
and massive internal storage capacity in a rack or tower platform.
The scalable Dell PowerEdge T640 drives a wide range of workloads for mid-sized
offices, remote sites and data centers
Dell PowerEdge T640
Features Technical Specification
Processor Up to two 2nd Generation Intel® Xeon® Scalable processors, up to 28 cores per processor
Memory 24 DDR4 DIMM slots, Supports RDIMMS/ LRDIMMS, speeds up to 2993MT/s, 3TB max
Up to 12 NVDIMM, 192GB max
Supports registered ECC DDR4 DIMMs only
Storage controllers Internal controllers: PERC H330, H730P, H740P, HBA330, Software RAID (SWRAID) S140
Boot Optimized Storage Subsystem: HWRAID 2 x M.2 SSDs 120GB, 240 GB
External PERC (RAID): H840
External HBAs (non-RAID): 12 Gbps SAS HBA
Drive bays Up to 8 or 18 x 3.5” SAS/SATA (HDD/SSD) max 288TB or up to 16 x 2.5” SAS/SATA (HDD/SSD) max 61TB or
up to 32 x 2.5” SAS/SATA (HDD/SSD) max 122TB or up to 16 x 2.5″ with up to 8 NVMe, SAS/SATA /NVMe (HDD/SSD) max 112TB
Power supplies Titanium 750W, Platinum 495W, 750W, 1100W,
1600W, 2000W and 2400W
48VDC 1100W, 240HVDC 750W
Hot plug power supplies with full redundancy
Up to 8 fans with N+1 redundancy (6 hot-pluggable internal fans
plus 2 external fans)1
Sizing Form factor: Tower or rack, 5U Chassis max depth: 708.7 mm
Bezel Optional security bezel
Embedded / At-Server iDRAC9 with Lifecycle Controller
iDRAC Direct
iDRAC REST API with Redfish
Quick Sync 2 BLE/wireless module
Consoles & Mobile OpenManage Enterprise OpenManage Mobile
OpenManage Power Manager
Integrations Microsoft® System Center, VMware® vCenter™, BMC Software
Connections Nagios & Nagios XI, HP Operations Manager (OMi)
Tools Dell EMC Repository Manager
Dell EMC Update Package
Dell EMC System Update
Dell EMC Server Update Utility
iDRAC Service Module
OpenManage Server Administrator
OpenManage Storage Services
Security TPM 1.2/2.0 optional
Cryptographically signed firmware
Silicon Root of Trust
Secure Boot
System Lockdown
System Erase
I/O & Ports 2 x 10GbE LOM (1GbE/10GbE)
8 x USB (1 x USB 2.0, 1 x USB 3.0, 6 x USB 2.0/3.0) dedicated IDRAC Direct Micro-USB
Video card: VGA
Up to 8 PCIe Gen3 slots
GPU options2 GPU options: 4 x DW or 8 x SW
Nvidia Tesla P100, K80M, M60, M10, P40, AMD
S7150, S7150X22
See Dell.com/GPU for the latest information.
Supported operating
systems
Canonical® Ubuntu® LTS
Citrix® Hypervisor
Microsoft Windows Server® LTSC with Hyper-V
Red Hat® Enterprise Linux
SUSE® Linux Enterprise Server
VMware® ESXi®
For specifications and interoperability details,
see Dell.com/OSsupport
OEM-ready version
available
From bezel to BIOS to packaging, your servers can look and feel as if they were designed and built by you.
For more information, visit Dell.com/OEM.
Recommended support
and services
Choose Dell ProSupport Plus for critical systems or Dell ProSupport for premium hardware and software support for your Dell PowerEdge T640
solution. Consulting and deployment offerings are also available. Contact your Dell representative today for more information. Availability
and terms of Dell Services vary by region. For more information, visit dell.com/itlifecycleservices.
Dell Financial Services Deliver results with easy financing. Explore financial options that move at the speed of business.
For more information, visit https://www.emc.com/products/how-to-buy/global-financial-services/index.htm
Dell PowerEdge T640 Tower Server
Get the Dell PowerEdge T640 3104 at the best price in Kenya from Wodex Technologies
Scale as your workloads evolves, with peak 2-socket server performance and huge internal storage capacity.
Accelerate modern workloads with a scalable platform
The Dell PowerEdge T640 is a versatile, powerhouse server ideal for mid-sized offices, remote sites and data centers. The Dell PowerEdge T640 combines powerful performance and massive internal storage capacity in a rack or tower platform. Address a wide range of workloads and future-proof your data center with flexible storage, performance and I/O options.
Great for:
- Server virtualization, desktop virtualization
- Consolidation
- Database, business analytics (BI) and intelligence
- Applications and imaging for medical, finance, education and science
- ERP, CRM, HPC
- Software-defined technologies
Adapt and scale with greater versatility
Meet evolving business needs with the scalable business architecture of the Dell PowerEdge T640. Accelerate demanding workloads and plan for future growth with cost-effective, in-server expansion.
- Deliver fast insights with up to 8 NVMe drives and 2 x 10GbE connections.
- Scale compute resources with Intel® Xeon® Scalable processors that deliver a 27% increase in cores and 50% increase in bandwidth over the previous generation.1
- Address massive data growth with up to 18 x 3.5″ or 32 x 2.5″ drives and 8 PCIe slots.
- Provide advanced imaging and VDI with up to 4 x 300W GPU accelerators.
Enhance productivity with intelligent automation
Dell PowerEdge T640 OpenManage intelligent automation enables you to spend less time on routine maintenance so you can focus on business-critical priorities.
- Help maximize uptime and reduce the IT effort to resolve issues by up to 72%2 with ProSupport Plus and SupportAssist.
- Leverage existing management consoles with easy integrations for VMware® vSphere®, Microsoft® System Center and Nagios®.
- Improve productivity with agent-free Dell iDRAC9 for automated management.
- Simplify deployment with OpenManage next-generation console and server profiles to configure and prep servers rapidly and scalably.
Protect your business with integrated security
A comprehensive, cyber-resilient architecture with security embedded into every server helps to protect your data.
- Protect server configuration and firmware from malicious changes with new Configuration Lock-down.
- Use system erases of local storage to help ensure data privacy when you repurpose or retire servers.
- Automate updates that check file dependencies and proper update sequence, before deploying them independently from the OS/hypervisor.
- Take control of your firmware consoles with embedded authentication that is designed to allow only properly signed updates to run.
