HP EliteDesk 800 G3 Tower Business PC System features
HP EliteDesk 800 G3 Tower Business PC
HP EliteDesk 800 G3 Tower Business PC Processors
|
Specification
|
Description
|
|
Intel Core i7-7700K processor
|
91 W
Up to 4.5 GHz maximum Turbo Frequency (4.2 GHz base frequency)
8 MB cache, 4 cores, 8 threads
Intel HD Graphics 630
DDR4 memory up to 2400 MT/s data rate
|
|
Intel Core i7-7700 processor
|
65 W
Up to 4.2 GHz maximum Turbo Frequency (3.6 GHz base frequency)
8 MB cache, 4 cores, 8 threads
Intel HD Graphics 630
DDR4 memory up to 2400 MT/s data rate
Supports Intel vPro Technology and Intel Stable Image Platform Program (SIPP)
|
|
Intel Core i5-7600 processor
|
65 W
Up to 4.1 GHz maximum Turbo Frequency (3.5 GHz base frequency)
6 MB cache, 4 cores, 4 threads
Intel HD Graphics 630
DDR4 memory up to 2400 MT/s data rate
Supports Intel vPro Technology and Intel Stable Image Platform Program (SIPP)
|
|
Intel Core i5-7500 processor
|
65 W
Up to 3.8 GHz maximum Turbo Frequency (3.4 GHz base frequency)
6 MB cache, 4 cores, 4 threads
Intel HD Graphics 630
DDR4 memory up to 2400 MT/s data rate
Supports Intel vPro Technology and Intel Stable Image Platform Program (SIPP)
|
|
Intel Core i3-7320 processor
|
51 W
4.1 GHz base frequency
4 MB cache, 2 cores, 4 threads
Intel HD Graphics 630
DDR4 memory up to 2400 MT/s data rate
|
|
Intel Core i3-7300 processor
|
51 W
4.0 GHz base frequency
4 MB cache, 2 cores, 4 threads
Intel HD Graphics 630
DDR4 memory up to 2400 MT/s data rate
|
|
Intel Core i3-7100 processor
|
51 W
3.9 GHz base frequency
3 MB cache, 2 cores, 4 threads
Intel HD Graphics 630
DDR4 memory up to 2400 MT/s data rate
|
|
Intel Core i7-6700 processor
|
65 W
Up to 4.0 GHz maximum Turbo Frequency (3.4 GHz base frequency)
8 MB cache, 4 cores, 8 threads
Intel HD Graphics 530
DDR4 memory up to 2133 MT/s data rate
Supports Intel vPro Technology and Intel Stable Image Platform Program (SIPP)
|
|
Intel Core i5-6600 processor
|
65 W
Up to 3.9 GHz maximum Turbo Frequency (3.3 GHz base frequency)
6 MB cache, 4 cores, 4 threads
Intel HD Graphics 530
DDR4 memory up to 2133 MT/s data rate
Supports Intel vPro Technology and Intel Stable Image Platform Program (SIPP)
|
|
Intel Core i5-6500 processor
|
65 W
Up to 3.6 GHz maximum Turbo Frequency (3.2 GHz base frequency)
6 MB cache, 4 cores, 4 threads
Intel HD Graphics 530
DDR4 memory up to 2133 MT/s data rate
Supports Intel vPro Technology and Intel Stable Image Platform Program (SIPP)
|
|
Intel Core i3-6100 processor
|
51 W
3.7 GHz base frequency
3 MB cache, 2 cores, 4 threads
Intel HD Graphics 530
DDR4 memory up to 2133 MT/s data rate
|
|
Intel Pentium G4560 processor
|
54 W
3.5 GHz base frequency
3 MB cache, 2 cores, 4 threads
Intel HD Graphics 610
DDR4 memory up to 2400 MT/s data rate
|
|
Intel Pentium G4600 processor
|
51 W
3.6 GHz base frequency
3 MB cache, 2 cores, 4 threads
Intel HD Graphics 630
DDR4 memory up to 2400 MT/s data rate
|
|
Intel Pentium G4620 processor
|
51 W
3.7 GHz base frequency
3 MB cache, 2 cores, 4 threads
Intel HD Graphics 630
DDR4 memory up to 2400 MT/s data rate
|
|
Intel Celeron G3930 processor
|
51 W
2.9 GHz base frequency
2 MB cache, 2 cores, 2 threads
Intel HD Graphics 610
DDR4 memory up to 2133 MT/s data rate
|
|
Intel Celeron G3950 processor
|
51 W
3.0 GHz base frequency
2 MB cache, 2 cores, 2 threads
Intel HD Graphics 610
DDR4 memory up to 2133 MT/s data rate
|
|
Chipset
|
Intel Q270
|
NOTE:
In accordance with Microsoft support policy, this product does not support Windows 8 or Windows 7. HP does not support the Windows 8 or Windows 7 operating system on products configured with Intel and AMD 7th generation or later processors, or provide any Windows 8 or Windows 7 drivers.Multicore is designed to improve performance of certain software products. Not all customers or software applications necessarily benefit from use of this technology. 64-bit computing system required. Performance and clock frequency vary depending on application workload and hardware and software configurations. Intel numbering is not a measurement of higher performance.
HP EliteDesk 800 G3 Tower Business PC Memory
|
Specification
|
Description
|
|
DDR4-2400
|
Maximum: 64 GB
Number of slots: (4) DIMM (all slots are customer accessible/upgradeable)
Up to 2400 MT/s
|
|
Configurations
|
2048 MB total system memory (2048 MB x 1) (AMO only)
4096 MB total system memory (4096 MB x 1)
8192 MB total system memory (8192 MB x 1)
16384 MB total system memory (16384 MB x 1)
|
NOTE:
Addressing memory above 4 GB requires a 64-bit operating system. With Windows 32-bit operating systems, the amount of usable memory is dependent upon the configuration, therefore above 3 GB, all memory might not be available due to system resource requirements.Memory modules support data transfer rates up to 2400 MT/s; actual data rate is determined by the system configured processor. See processor specifications for supported memory data rate.
Storage
|
Specification
|
Description
|
|
SATA drives
|
500 GB, 7.2 K rpm, SATA 6.0 Gb/s, 6.35 cm (2.5 in)
1 TB, 7.2 K rpm, SATA 6.0 Gb/s, 6.35 cm (2.5 in)
500 GB, 7.2 K rpm, SATA 3.0 (6.0 Gb/s), 8.89 cm (3.5 in)
1 TB, 7.2 K rpm, SATA 3.0 (6.0 Gb/s), 8.89 cm (3.5 in)
2 TB, 7.2 K rpm, SATA 6.0 Gb/s NCQ, 8.89 cm (3.5 in)
|
|
Self-Encrypting drives (SED HDD)
|
500 GB, 5.4 K rpm, SATA 6.0 Gb/s, 6.35 cm (2.5 in), Federal Information Processing Standard (FIPS) SED
500 GB, 7.2 K rpm, SATA 2.0 (3.0 Gb/s), 6.35 cm (2.5 in), SED Opal 2
|
|
Self-Encrypting drives (SED SSD)
|
256 GB, SATA 6.0 Gb/s, 6.35 cm (2.5 in), SED Opal 2
512 GB, SATA 6.0 Gb/s, 6.35 cm (2.5 in), SED Opal 2
256 GB, SATA 6.0 Gb/s, 6.35 cm (2.5 in), Federal Information Processing Standard (FIPS) SED
512 GB, SATA 6.0 Gb/s, 6.35 cm (2.5 in), Federal Information Processing Standard (FIPS) SED
|
|
Solid State Hybrid drives (SSHD)
|
500 GB, 5.4 K rpm, SATA 6.0 Gb/s, 6.35 cm (2.5 in), 8 GB Hybrid
1 TB, 5.4 K rpm, SATA 6.0 Gb/s, 6.35 cm (2.5 in), 8 GB Hybrid
1 TB, 7.2 K rpm, SATA, 8.89 cm (3.5 in), 8 GB Hybrid
|
|
PCIe NMVe TLC SSD drives
|
256 GB, PCI-E Gen3 x 4, Turbo Drive G2 TLC SSD
512 GB, PCI-E Gen3 x 4, Turbo Drive G2 TLC SSD
1 TB, PCI-E Gen3 x 4, Turbo Drive G2 TLC SSD
|
|
2.5 in SATA SSD drives
|
SATA 128 GB, SATA 3.2 (6.0 Gb/s), 6.35 cm (2.5 in)
SATA 256 GB, SATA 3.2 (6.0 Gb/s), 6.35 cm (2.5 in)
|
|
Optical disc drives
|
HP 9.5 mm (0.37 in) 800 G3 Tower DVD-Writer
HP 9.5 mm (0.37 in) 800 G3 Tower DVD-ROM
|
|
Removable drives
|
HP 9.5 mm (0.37 in), Slim Removable SATA 500 GB
HP 8.89 cm (3.5 in) Removable SATA HDD frame/carrier
|
|
Media Card Reader (optional)
|
SD4 with 5-in-1 Interface from SD option to PCA is USB (supports SD, SDXC, SDHC, UHS-I, UHS-II)
|
NOTE:
For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 30 GB of system disk is reserved for the system recovery software.
HP EliteDesk 800 G3 Tower Business PC Networking/communications
|
Specification
|
Description
|
|
Ethernet (RJ-45) (integrated)
|
Intel I219LM Gigabit Network Connection LOM (standard)
Intel Ethernet I210-T1 PCIe x1 Gb Network Interface Card (optional)
|
|
Wireless LAN (optional)
|
Intel 7265 802.11ac 2×2 Wi-Fi with Bluetooth M.2 Combo Card non-VPro
Intel 8265 802.11ac 2×2 Wi-Fi with Bluetooth M.2 Combo Card non-Vpro (802.11ac Wave 2 supported)
Intel 3168 802.11ac 2×2 Wi-Fi with Bluetooth M.2 Combo Card non-Vpro
Intel 8265 802.11ac 2×2 Wi-Fi with Bluetooth M.2 Combo Card Vpro (802.11ac Wave 2 supported)
|
NOTE:
Wireless access point and Internet service required and not included. Availability of public wireless access points limited.
HP EliteDesk 800 G3 Tower Business PC Audio/multimedia
|
Specification
|
Description
|
|
Type
|
Conexant CX20632 Audio Codec (all ports are stereo)
|
|
Audio in/out ports
|
Headset and headphone front ports1, 3.5 mm (.14 in)
Line-out and line-in rear ports1, 3.5 mm (.14 in)
|
|
Internal speaker (standard)
|
Yes
2.0 W amplifier
|
|
Multi-streaming capable1
|
Yes
|
NOTE:
1The front headset connector supports CTIA style headsets and is re-taskable as a Line-in, Microphone-in, or Headphone-out port. Rear audio input ports are re-taskable as a Line-in or Microphone-in port. External speakers must be powered externally. Multi-streaming can be enabled in the audio control panel to allow independent audio streams to be sent to/from the front and rear jacks or internal speakers. This allows for different audio applications to use separate audio ports on the system. For example, the front jacks could be used with a headset for a communications application while the rear jacks are being used with external speakers and a multimedia application.hp elitedesk 800 g3 tower pc price,hp elitedesk 800 g3 tower drivers,hp elitedesk 800 g3 price,hp elitedesk 800 g3 – sff specs,hp elitedesk 800 g3 mini specs,hp elitedesk 800 g3 tower price in kenya,hp elitedesk 800 g3 twr price,hp elitedesk 800 g3 tower motherboard,hp elitedesk 800 g2 tower
HP EliteDesk 800 G3 Tower Business PC Power supply
|
Specification
|
Description
|
|
80 PLUS Bronze
|
250 W active PFC; 82/85/82% efficient at 20/50/100% load (115 V)
|
|
80 PLUS Gold
|
500 W active PFC; 87/90/87% efficient at 20/50/100% load (115 V)
88/91/88% efficient at 20/50/100% load (230 V)
|
|
80 PLUS Platinum
|
250 W active PFC; 90/92/89% efficient at 20/50/100% load (115 V)
91/93/90% efficient at 20/50/100% load (230 V)
|
|
Rated input current with energy efficient1 power supply
|
250 W Bronze/3.5 A
250 W Platinum/3 A
500 W Gold/6 A
|
|
Operating voltage range
|
90 – 264 VAC
|
|
Rated voltage range
|
100 – 240 VAC
|
|
Rated line frequency
|
50/60 Hz
|
|
Operating line frequency
|
47 – 63 Hz
|
|
DC output
|
+12.1 V
|
|
Current leakage (NFPA 99: 2102)
|
Less than 500 µA of leakage current at 120 Vac with the ground wire disconnected, as required for Non-patient electrical appliances and equipment used in a patient care facility or those contact patients in normal use. Per section 10.3.5.1.
Less than 100 µA of leakage current at 120 Vac with the ground wire intact with normal polarity, as required for Non-patient electrical appliances and equipment used in a patient care facility or that contact patient in normal use. Per section 10.3.5.1.
|
|
Power supply fan
|
70 mm variable speed
|
|
Power cord
|
1.83 m (6.0 ft)
|
NOTE:
1High efficiency power supply is a requirement for ENERGY STAR certification in conjunction with a select range of processors and modules.
HP EliteDesk 800 G3 Tower Business PC Keyboards/pointing devices
|
Specification
|
Description
|
|
Keyboards
|
HP Conferencing keyboard
HP USB PS/2 washable keyboard1
HP USB Business Slim keyboard
HP USB Business Slim CCID SmartCard keyboard
HP USB PS/2 Business Slim keyboard1
HP USB Business Slim keyboard (China only)
HP USB Business Slim grey keyboard
|
|
Mice
|
HP PS/2 mouse1
HP USB 1000 dpi laser mouse
HP Grey V2 mouse
HP USB mouse
HP USB PS/2 washable mouse1
HP USB mouse (China only)
HP USB hardened mouse
|
|
Combos
|
HP Wireless Business Slim keyboard and mouse
HP USB keyboard and mouse (China only)
|
|
Mouse pad
|
HP mouse pad
|
NOTE:
1Optional HP internal serial/PS/2 ports are required to support this device.
HP EliteDesk 800 G3 Tower Business PC Input/Output devices
|
Specification
|
Description
|
|
Optional ports (only one can be chosen)
|
HP DisplayPort port
HP Type-C port
HP HDMI port
HP VGA port
HP internal serial port1
HP internal serial/PS/2 ports1
HP PCIe x1 parallel port card
HP PCIe x1 SuperSpeed USB 3.1 Gen 2 Type-C card
HP EliteDesk 800 G3 Small Form Factor dust filter
|
NOTE:
Must be configured at purchase except for PCIe x1 cards.1 Internal serial port and HP internal serial/PS/2 ports can both be selected for SFF.
HP EliteDesk 800 G3 Tower Business PC Adapters and cables
|
Specification
|
Description
|
|
Adapters (optional)
|
HP DisplayPort to DVI-D adapter
HP DisplayPort to HDMI 4K adapter
HP DisplayPort to VGA adapter
|
|
Cables (optional)
|
HP DisplayPort cable
HP DVI cable
|
HP EliteDesk 800 G3 Tower Business PC Graphics
|
Specification
|
Description
|
|
Intel HD Graphics (integrated)
|
Intel HD Graphics 530
Intel Core i7 processor
Intel Core i5 processor
Intel Core i3 processor
Intel HD Graphics 630
Intel Core i7 processor
Intel Core i5 processor
Intel Core i3 processor
Intel Pentium G4620 processor
Intel Pentium G4600 processor
Intel Pentium G4600T processor
Intel HD Graphics 610
Intel Pentium G4560 processor
Intel Pentium G4560T processor
Intel Celeron G3950 processor
Intel Celeron G3930 processor
Intel Celeron G3930T processor
|
|
Optional
|
AMD Radeon R7 450 4 GB FH PCIe x16 (requires 500 W chassis)
AMD Radeon RX 460 2 GB FH PCIe x16 (requires 500 W chassis)
AMD Radeon RX 480 4 GB FH PCIe x16 (requires 500 W chassis and 500 W PSU and will be available after launch)
NVIDIA GeForce GT 730 1 GB PCIe x8 HDMI
NVIDIA GeForce GT 730 2 GB PCIe x8 DP
NVIDIA GeForce GTX 1080 8 GB FH PCIe x16 (requires 500 W chassis and 500 W PSU and will be available after launch)
2nd Graphics Cards
AMD Radeon R7 450 4 GB FH PCIe x16 G5
NVIDIA GeForce GT 730 1 GB PCIe x8 HDMI
NVIDIA GeForce GT 730 2 GB PCIe x8 DP
|
Ports/slots/bays
|
Specification
|
Description
|
|
Ports
|
Standard
(4) USB 2.0: (2) front; (2) rear
(6) USB 3.1 Gen 1: (2) front (including 1 fast charging); (4) rear
(1) USB Type-C 3.1 Gen1, front; (1) USB Type-C 3.1 Gen1 (optional), rear
(1) PS/2 (optional with serial card)
(2) DisplayPort with multi-stream
(1) DisplayPort (optional)
(1) VGA (optional)
(1) HDMI (optional)
(1) USB-C (optional) (has alternate mode DisplayPort or 15 W output)
(1) Front: Audio-out (headphone)/Audio-in (microphone) combo jack; (1) Audio-out (headphone) jack
(1) Rear: Audio-out jack for powered audio devices; (1) Audio-in jack
(1) RJ-45 Ethernet port
Optional
(1) Serial (RS-232)
(1) Serial (RS-232) and PS/2 combination (rear)
Internal
(5) Internal SATA storage connectors
|
|
Expansion slots
|
(1) Turbo Drive (M.2 PCIe)
M.2 PCIe x1-2230 (for WLAN)
(1) Turbo Drive (M.2 PCIe)
M.2 PCIe x4-2280 (for storage)
(2) PCI Express x1 (v3.0)
10.67 cm (4.2 in) full height
16.76 cm (6.6 in) length
10 W maximum power
(1) PCI Express x16 (v3.0); wired as an x4
10.67 cm (4.2 in) full height
16.76 cm (6.6 in) length
35 W maximum power
(1) PCI Express x16 (v3.0)
10.67 cm (4.2 in) full height
16.76 cm (6.6 in) length
75 W maximum power
|
|
Bays
|
(1) 13.34 cm (5.25 in) Half Height ODD
(1) 6.35 cm (2.5 in) internal storage drive
(2) 8.89 cm (3.5 in) internal storage drive
(1) Secure Digital (SD) 4 Reader
(1) 9 mm (0.35 in) Slim ODD
|
HP EliteDesk 800 G3 Tower Business PC Physical specifications
|
Specification
|
Description
|
|
Chassis (W x H x D) (not including bezel)
|
154.94 x 365.76 x 370.84 mm (6.1 x 14.4 x 14.6 in)
|
|
System volume
|
1269 cu in
20.8 L
|
|
System weight
|
9.86 kg (21.74 lbs)
|
|
Maximum supported weight (desktop orientation)
|
35 kg (77.16 lbs)
|
|
Packaged (H x W x D)
|
516.89 x 298.96 x 478.03 mm (20.35 x 11.77 x 18.82 in)
|
|
Shipping weight
|
11.34 kg (25.0 lbs)
|
|
Palletization profile
|
8 units per layer; 4 layers maximum; 32 per pallet
1199.90 x 1000.0 x 119.89 mm (47.24 x 39.37 x 4.72 in) (including pallet)
|
HP EliteDesk 800 G3 Tower Business PC Software
|
Specification
|
Description
|
|
BIOS
|
HP Sure Start Gen3
HP DriveLock/HP Automatic DriveLock
BIOS Update via Network
Master Boot Record Security
Power On Authentication
Secure Erase
Absolute Persistence Module1
Pre-boot Authentication
HP LAN-WLAN Protection
HP Wireless Wakeup
|
|
Communication/Connectivity
|
Native Miracast Support
|
|
Multimedia
|
Cyberlink Power Media Player (select models only)
Cyberlink Power2Go (select models only)
|
|
HP Value Add Software
|
HP ePrint Driver with JetAdvantage2
HP Hotkey Support – CMIT
HP Recovery Manager
HP Recovery Disc Creator (Windows 7 only)
HP Jumpstart
HP Support Assistant
HP Noise Cancellation Software
HP Velocity
HP Notifications
|
|
3rd party
|
Foxit PhantomPDF Express for HP (Windows 7 only)
|
|
Microsoft products
|
Buy Office
Bing Search
Skype (not available in China)
|
|
Manageability
|
HP Driver Packs (available for download)
HP Softpaq Download Manager (SDM)
HP System Software Download Manager (SSM) (available for download)
HP BIOS Config Utility (BCU) (subscription required)
HP Client Catalog (available for download)
HP Manageability & Integration Kit (MIK) (available for download)
LANDESK Management (subscription required)
Discover HP Touchpoint Manager3
For more information about manageability software, go to the HP Client Management Solutions webpage.
|
|
Client security software
|
HP Client Security
HP Security Manager (including Credential Manager and Password Manager)
HP DriveLock
HP Password Manager
HP WorkWise (requires Bluetooth)
Absolute Persistence Module
Power On Authentication
Microsoft
Microsoft Defender
Microsoft Security Essentials (Windows 7 only)
|
NOTE:
1Absolute agent is activated when customers activate a purchased subscription. Subscriptions can be purchased for terms ranging multiple years. Service is limited, check with Absolute for availability outside the U.S. The Absolute Recovery Guarantee is a limited warranty. Certain conditions apply. Data Delete is an optional service provided by Absolute Software. If utilized, the Recovery Guarantee is null and void. In order to use the Data Delete service, customers must first sign a Pre-Authorization Agreement and either obtain a PIN or purchase one or more RSA SecurID tokens from Absolute Software.2Requires an Internet connection to HP web-enabled printer and HP ePrint account registration. Requires optional broadband module. Broadband use requires separately purchased service contract. Check with service provider for coverage and availability in your area. Separately purchased data plans or usage fees might apply. Print times and connection speeds vary.3Requires purchase of a subscription and supports Android, iOS, and Windows 7 or higher operating systems and PCs, notebooks, tablets and smartphones from various manufacturers. Not available in all countries/regions.
HP EliteDesk 800 G3 Tower Business PC Operating systems
|
Specification
|
Description
|
|
Pre-installed (Windows)
|
Windows 10 Pro 641
Windows 10 Pro 64 (National Academic License)3
Windows 10 Home 641
Windows 10 Home Single Language 641
Windows 7 Professional 64 (available through downgrade rights from Windows 10 Pro)2,4
Windows 7 Professional 32 (available through downgrade rights from Windows 10 Pro)2,4
|
|
Pre-installed (other)
|
FreeDOS 2.0
NeoKylin Linux 64
|
|
Web-supported
|
Windows 10 Enterprise 641
Windows 7 Enterprise 644
|
NOTE:
1Not all features are available in all editions or versions of Windows. Systems might require upgraded and/or separately purchased hardware, drivers, software, or BIOS update to take full advantage of Windows functionality. Windows 10 automatic updates are always enabled. ISP fees might apply and additional requirements might apply over time for updates.2This system is preinstalled with Windows 7 Pro software and also comes with a license and media for Windows 10 Pro software. Only one version of the Windows software can be used at a time. Switching between versions requires you to uninstall one version and install the other version. You must back up all data (files, photos, etc.) before uninstalling and installing operating systems to avoid loss of data.3Some devices for academic use automatically update to Windows 10 Pro Education with the Windows 10 Anniversary Update. Features vary; for more information, see Windows 10 Pro Education features.4Only available with 6th generation (Intel) processors.
HP EliteDesk 800 G3 Tower Business PC Environmental
|
Specification
|
Description
|
|
ENERGY STAR
|
Certified models available
|
|
EPEAT
|
Registered where applicable/supported
Low halogen (chassis, all internal components, and modules)
|
|
TAA compliance
|
TAA compliant models available
|
HP EliteDesk 800 G3 Tower Business PC Security
|
Specification
|
Description
|
|
Software security (standard)
|
Trusted Platform Module (TPM) 2.0 (Infineon SLB9670) (Common Criteria EAL4+ certified)
Downgradeable to TPM 1.2
Convertible to FIPS 140-2 Certified mode (TPM 2.0 is not available for Win 7 32-bit). Restrictions apply; contact the account manager for more details.
|
|
Hardware security
|
SATA 0,1 port disablement (via BIOS)
Serial, USB enable/disable (via BIOS)
Solenoid Hood Lock/intrusion sensor
Chassis padlocks and cable lock devices supported
|
-
HP EliteDesk 800 G3 Tower Business PC Operating system
- Windows 10 Pro 64
- Processor family
-
- 7th Generation Intel® Core™ i7 processor
- Processor
- Intel® Core™ i7-7700 with Intel® HD Graphics 630 (3.6 GHz base frequency, up to 4.2 GHz with Intel® Turbo Boost Technology, 8 MB cache, 4 cores)
- Chipset
- Intel® Q270
- Form factor
- Tower
- Management features
-
- HP Client Catalog
- HP Driver Packs
- LANDESK Management
- HP SoftPaq Download Manager (SDM)
- HP System Software Manager (SSM)
- HP BIOS Config Utility (BCU)
- HP Image Assistant
- HP MIK for Microsoft SCCM
- Environmental
-
- Low halogen
HP EliteDesk 800 G3 Tower Business PC Memory
- Memory, standard
-
- 4 GB DDR4-2400 SDRAM (1 x 4 GB)
(Transfer rates up to 2400 MT/s)
- Memory Slots
- 4 DIMM
HP EliteDesk 800 G3 Tower Business PC Storage
- Internal drive bays
- One 6.35 cm (2.5″); One 8.9 cm (3.5″); One 13.34 cm (5.25″)
- External drive bays
- One 9.5 mm slim
- Internal drive
- 3.5″ 500 GB 7200 rpm SATA
- Optical drive
-
- Slim DVD-Writer
HP EliteDesk 800 G3 Tower Business PC Display and graphics
- Graphics
- Integrated:
Intel® HD Graphics 630 20,27
HP EliteDesk 800 G3 Tower Business PC Expansion features
- Ports
- Front:
1 SD 4 card reader (optional)
1 Headphone connector
1 USB 2.0 (fast charging)
1 USB 2.0
2 USB 3.1 Gen 1
1 USB Type-C™ (charging)
Universal audio jack with CTIA headset support
Back:
1 audio out
2 DisplayPort™
2 USB 2.0
4 USB 3.1 Gen 1
1 audio in
1 RJ-45
1 power connector
3 optional ports
Back (optional):
1 HDMI 22
- Expansion slots
-
- 1 M.2 2230 for optional wireless NIC
- 1 M.2 internal connector for optional SSD drive
- 1 PCIe x1
- 1 PCIe 3.0 x16
- PCI Express x16 (v3.0)(wired as a x4) 6.35 cm (2.5″) low profile, 16.76 cm (6.6″) length, 35 W max power
HP EliteDesk 800 G3 Tower Business PC Media devices
- Audio
- Integrated Realtek ALC221 with combo microphone/headphone jack, line-in and line-out rear ports (3.5 mm), internal speaker.
Communications
- Network interface
- Intel® I219LM Gigabit Network Connection LOM
HP EliteDesk 800 G3 Tower Business PC Power and operating requirements
Energy efficiency
-
- ENERGY STAR® certified
- Power supply
-
- 250 W standard efficiency
- Operating temperature range
- 10 to 35°C
- Operating humidity range
- 10 to 90% RH
HP EliteDesk 800 G3 Tower Business PC Dimensions and weight
- Dimensions (W x D x H)
- 15.4 x 36.9 x 36.5 cm
(Dimensions are WxDxH with product in horizontal orientation)
- Weight
- 9.86 kg
HP EliteDesk 800 G3 Tower Business PC Security management
-
- Trusted Platform Module TPM 2.0 Embedded Security Chip (SLB9670 – Common Criteria EAL4+ Certified)
- SATA 0,1 port disablement (via BIOS)
- Drive lock
- RAID configurations
- Serial, USB enable/disable (via BIOS)
- Power-on password (via BIOS)
- Setup password (via BIOS)
- Solenoid hood lock/intrusion sensor
- Support for chassis padlocks and cable lock devices
Reviews
There are no reviews yet.
