HP Z2 Tower G4 arbetsstation Intel® Xeon® E-2174G 32 GB DDR4-SDRAM 512 GB SSD Black Workstation Windows 10 Pro for Workstations
Roll over image to zoom in
HP Z2 Tower G4 arbetsstation Intel® Xeon® E-2174G 32 GB DDR4-SDRAM 512 GB SSD Black Workstation Windows 10 Pro for Workstations
HP Z2 Tower G4 Product image
HP Z2 Tower G4 Operating system
HP Z2 Tower G4 Feature
|
Description
HP Z2 Tower G4
|
Preinstalled
|
Windows 10 Pro for Workstations 64
Windows 10 Pro 64 (recommended by HP)
Windows 10 Pro 64 (National Academic License)
Windows 10 Home 64
HP Linux Ready
|
Supported
|
Red Hat Enterprise Linux (RHEL) Workstation (12-month paper license available, not preinstalled)
|
HP Z2 Tower G4 Processors
HP Z2 Tower G4 Specification
|
Description
|
Intel Xeon processor E-2286G
|
Up to 4.9 GHz with Intel Turbo Boost Technology (4.0 GHz base frequency)
12 MB cache and 6 cores
Intel UHD Graphics P630
DDR4 memory up to 2666 MT/s data rate
80 W TDP
Intel vPro Technology
|
Intel Xeon processor E-2278G
|
Up to 5.0 GHz with Intel Turbo Boost Technology (3.4 GHz base frequency)
16 MB cache and 8 cores
Intel UHD Graphics P630
DDR4 memory up to 2666 MT/s data rate
80 W TDP
Intel vPro Technology
|
Intel Xeon processor E-2276G
|
Up to 4.9 GHz with Intel Turbo Boost Technology (3.8 GHz base frequency)
12 MB cache and 6 cores
Intel UHD Graphics P630
DDR4 memory up to 2666 MT/s data rate
80 W TDP
Intel vPro Technology
|
Intel Xeon processor E-2274G
|
Up to 4.9 GHz with Intel Turbo Boost Technology (4.0 GHz base frequency)
8 MB cache and 4 cores
Intel UHD Graphics P630
DDR4 memory up to 2666 MT/s data rate
80 W TDP
Intel vPro Technology
|
Intel Xeon processor E-2244G
|
Up to 4.8 GHz with Intel Turbo Boost Technology (3.8 GHz base frequency)
8 MB cache and 4 cores
Intel UHD Graphics P630
DDR4 memory up to 2666 MT/s data rate
80 W TDP
Intel vPro Technology
|
Intel Xeon processor E-2236
|
Up to 4.8 GHz with Intel Turbo Boost Technology (3.4 GHz base frequency)
12 MB cache and 6 cores
DDR4 memory up to 2666 MT/s data rate
80 W TDP
Intel vPro Technology
|
Intel Xeon processor E-2226G
|
Up to 4.7 GHz with Intel Turbo Boost Technology (3.4 GHz base frequency)
12 MB cache and 6 cores
Intel UHD Graphics P630
DDR4 memory up to 2666 MT/s data rate
80 W TDP
Intel vPro Technology
|
Intel Xeon processor E-2224G
|
Up to 4.6 GHz with Intel Turbo Boost Technology (3.4 GHz base frequency)
8 MB cache and 4 cores
Intel UHD Graphics P630
DDR4 memory up to 2666 MT/s data rate
80 W TDP
Intel vPro Technology
|
Intel Xeon E-2176G processor
|
Up to 4.7 GHz with Intel Turbo Boost Technology (3.7 GHz base frequency)
12 MB cache and 6 cores
Intel UHD Graphics P630
DDR4 memory up to 2666 MT/s data rate
80 W TDP
Intel vPro Technology
|
Intel Xeon E-2174G processor
|
Up to 4.7 GHz with Intel Turbo Boost Technology (3.8 GHz base frequency)
8 MB cache and 4 cores
Intel UHD Graphics P630
DDR4 memory up to 2666 MT/s data rate
71 W TDP
Intel vPro Technology
|
Intel Xeon E-2144G processor
|
Up to 4.5 GHz with Intel Turbo Boost Technology (3.6 GHz base frequency)
8 MB cache and 4 cores
Intel UHD Graphics P630
DDR4 memory up to 2666 MT/s data rate
71 W TDP
Intel vPro Technology
|
Intel Xeon E-2136 processor
|
Up to 4.5 GHz with Intel Turbo Boost Technology (3.3 GHz base frequency)
12 MB cache and 6 cores
DDR4 memory up to 2666 MT/s data rate
80 W TDP
Intel vPro Technology
|
Intel Xeon E-2126G processor
|
Up to 4.5 GHz with Intel Turbo Boost Technology (3.3 GHz base frequency)
12 MB cache and 6 cores
Intel UHD Graphics P630
DDR4 memory up to 2666 MT/s data rate
80 W TDP
Intel vPro Technology
|
Intel Xeon E-2124G processor
|
Up to 4.3 GHz with Intel Turbo Boost Technology (3.4 GHz base frequency)
8 MB cache and 4 cores
Intel UHD Graphics P630
DDR4 memory up to 2666 MT/s data rate
71 W TDP
Intel vPro Technology
|
Intel Xeon E-2104G processor
|
3.2 GHz base frequency
8 MB cache and 4 cores
Intel UHD Graphics P630
DDR4 memory up to 2666 MT/s data rate
65 W TDP
Intel vPro Technology
|
Intel Core i9-9900K processor
|
Up to 5.0 GHz with Intel Turbo Boost Technology (3.6 GHz base frequency)
16 MB cache and 8 cores
Intel UHD Graphics 630
DDR4 memory up to 2666 MT/s data rate
95 W TDP
16 GB Intel Optane memory
Intel vPro Technology
|
Intel Core i9-9900 processor
|
Up to 5.0 GHz with Intel Turbo Boost Technology (3.1 GHz base frequency)
16 MB cache and 8 cores
Intel UHD Graphics 630
DDR4 memory up to 2666 MT/s data rate
95 W TDP
16 GB Intel Optane memory
Intel vPro Technology
|
Intel Core i7-9700K processor
|
Up to 4.9 GHz with Intel Turbo Boost Technology (3.6 GHz base frequency)
12 MB cache and 8 cores
Intel UHD Graphics 630
DDR4 memory up to 2666 MT/s data rate
95 W TDP
16 GB Intel Optane memory
Intel vPro Technology
|
Intel Core i7-9700 processor
|
Up to 4.7 GHz with Intel Turbo Boost Technology (3.0 GHz base frequency)
12 MB cache and 8 cores
Intel UHD Graphics 630
DDR4 memory up to 2666 MT/s data rate
95 W TDP
16 GB Intel Optane memory
Intel vPro Technology
|
Intel Core i5-9600 processor
|
Up to 4.6 GHz with Intel Turbo Boost Technology (3.1 GHz base frequency)
9 MB cache and 6 cores
Intel UHD Graphics 630
DDR4 memory up to 2666 MT/s data rate
95 W TDP
16 GB Intel Optane memory
Intel vPro Technology
|
Intel Core i5-9500 processor
|
Up to 4.4 GHz with Intel Turbo Boost Technology (3.0 GHz base frequency)
9 MB cache and 6 cores
Intel UHD Graphics 630
DDR4 memory up to 2666 MT/s data rate
95 W TDP
16 GB Intel Optane memory
Intel vPro Technology
|
Intel Core i3-9100 processor
|
Up to 4.2 GHz with Intel Turbo Boost Technology (3.6 GHz base frequency)
8 MB cache and 4 cores
Intel UHD Graphics 630
DDR4 memory up to 2666 MT/s data rate
95 W TDP
Intel vPro Technology
|
Intel Core i7-8700K processor
|
Up to 4.7 GHz with Intel Turbo Boost Technology (3.7 GHz base frequency)
12 MB cache and 6 cores
Intel UHD Graphics 630
DDR4 memory up to 2666 MT/s data rate
95 W TDP
16 GB Intel Optane memory
Intel vPro Technology
|
Intel Core i7-8700 processor
|
Up to 4.6 GHz with Intel Turbo Boost Technology (3.2 GHz base frequency)
12 MB cache and 6 cores
Intel UHD Graphics 630
DDR4 memory up to 2666 MT/s data rate
65 W TDP
16 GB Intel Optane memory
Intel vPro Technology
|
Intel Core i5-8600 processor
|
Up to 4.2 GHz with Intel Turbo Boost Technology (3.1 GHz base frequency)
9 MB cache and 6 cores
Intel UHD Graphics 630
DDR4 memory up to 2666 MT/s data rate
65 W TDP
16 GB Intel Optane memory
Intel vPro Technology
|
Intel Core i5-8500 processor
|
Up to 4.0 GHz with Intel Turbo Boost Technology (3.0 GHz base frequency)
9 MB cache and 6 cores
Intel UHD Graphics 630
DDR4 memory up to 2666 MT/s data rate
65 W TDP
16 GB Intel Optane memory
Intel vPro Technology
|
Intel Core i3-8100 processor
|
3.6 GHz Base frequency
6 MB cache and 4 cores
Intel UHD Graphics 630
DDR4 memory up to 2400 MT/s data rate
65 W TDP
Intel vPro Technology
|
Intel Pentium Gold G5400 processor
|
3.7 GHz base frequency
4 MB cache and 2 cores
Intel UHD Graphics 610
DDR4 memory up to 2400 MT/s data rate
54 W TDP
Intel vPro Technology
|
Chipset
|
Intel C246
|
NOTE:
Multicore is designed to improve performance of certain software products. Not all customers or software applications necessarily benefit from use of this technology. Performance and clock frequency vary depending on application workload and hardware and software configurations. Intel numbering is not a measurement of higher performance.Intel Optane memory system acceleration does not replace or increase the DRAM in your system.Some functionality of the vPro technology – such as Intel Active management technology and Intel Virtualization technology require additional 3rd party software in order to run.Intel Turbo Boost is based on maximum GHz for a single core.
HP Z2 Tower G4 Graphics
HP Z2 Tower G4 Feature
|
Description
|
Integrated
|
Intel UHD Graphics P630
Intel UHD Graphics 630
Intel UHD Graphics 610
|
Entry 3D
|
AMD Radeon Pro WX 3100 4 GB Graphics
NVIDIA Quadro P400 2 GB Graphics
NVIDIA Quadro P620 2 GB Graphics
|
Mid-range 3D
|
Radeon Pro WX4100 4 GB GFX Graphics
NVIDIA Quadro P2000 5 GB Graphics
NVIDIA Quadro P1000 4 GB Graphics
|
High-end 3D
|
Radeon Pro WX7100 8 GB Graphics
NVIDIA Quadro P4000 8 GB Graphics
NVIDIA Quadro P5000 16 GB Graphics
NVIDIA Quadro RTX 4000 8 GB Graphics
NVIDIA Quadro RTX 5000 16 GB Graphics
NVIDIA Quadro RTX6000 24 GB Graphics
|
Graphics cable adapters
|
HP DisplayPort to Dual Link DVI Adapter
HP DisplayPort to DVI-D Adapter
HP DisplayPort to VGA Adapter
HP DisplayPort to HDMI Adapter
HP mini-DisplayPort to DP Adapter
HP USB-C to VGA Adapter
HP USB-C to HDMI Adapter
HP USB-C to DP Adapter
|
NOTE:
Intermixing integrated Intel UHD graphics and discrete graphics cards to drive more than three displays can be enabled using the Computer (F10) Setup Utility. However, HP recommends using only discrete graphics when four or fewer displays are required to be supported.Integrated Intel UHD graphics P630 is supported on the select Intel Xeon E processors. Intel Xeon E, Intel Core i3 and Intel Pentium processors can support either ECC or non-ECC memory. Intel Core i5/i7 processors only support non-ECC memory.
HP Z2 Tower G4 Memory
HP Z2 Tower G4 Specification
|
Description
|
Standard
|
(4) UDIMM slots supporting dual-channel memory
4 GB, 8 GB, 16, and 32 GB UDIMMs
|
Supported configurations
|
8 GB (1 x 8 GB) DDR4-2666 ECC
16 GB (2 x 8 GB) DDR4-2666 ECC
32 GB (4 x 8 GB) DDR4-2666 ECC
32 GB (2 x 16 GB) DDR4-2666 ECC
64 GB (4 x 16 GB) DDR4-2666 ECC
64 GB (2 x 32 GB) DDR4-2666 ECC
128 GB (4 x 32 GB) DDR4-2666 ECC
4 GB (1 x 4 GB) DDR4-2666 non-ECC
8 GB (2 x 4 GB) DDR4-2666 non-ECC
8 GB (1 x 8 GB) DDR4-2666 non-ECC
16 GB (2 x 8 GB) DDR4-2666 non-ECC
32 GB (4 x 8 GB) DDR4-2666 non-ECC
32 GB (2 x 16 GB) DDR4-2666 non-ECC
64 GB (4 x 16 GB) DDR4-2666 non-ECC
64 GB (2 x 32 GB) DDR4-2666 non-ECC
128 GB (4 x 32 GB) DDR4-2666 non-ECC
|
Maximum
|
Up to 128 GB
|
NOTE:
Maximum memory capacities assume Windows 64-bit operating systems or Linux. With Windows 32-bit operating systems, memory above 3 GB might not all be available due to system resource requirements.Two channels of DDR4 memory are supported. To realize full performance, at least one DIMM must be inserted into each channel.
HP Z2 Tower G4 Monitors/displays
HP Z2 Tower G4 Feature
|
Description
|
Supported
|
HP Z Display Z27n G2 27-inch IPS LED Backlit Monitor
HP Z Display Z24n G2 24-inch IPS LED Backlit Monitor
HP Z Display Z24nf G2 23.8-inch IPS Backlit Monitor
HP Z Display Z23n G2 23-inch IPS LED Backlit Monitor
HP Z Display Z22n G2 21.5-inch IPS LED Backlit Monitor
|
NOTE:
Resolutions are dependent upon monitor capability and resolution and color depth settings.
HP Z2 Tower G4 Storage and drives
HP Z2 Tower G4 Feature
|
Description
|
SATA 8.89 cm (3.5 in) Hard Drives
|
500 GB SATA 6 Gb/s 7200 HDD
1 TB SATA 6 Gb/s 7200 HDD
2 TB SATA 6 Gb/s 7200 HDD
4 TB SATA 6 Gb/s 7200 HDD
6 TB SATA 6 Gb/s 7200 HDD
500 GB SATA 7200 rpm SED SFF HDD
1 TB 7200 RPM SATA 8 GB SSHD Drive
1 TB Enterprise SATA 7200 HDD
|
SATA SSD
|
HP 256 GB SATA SSD
HP 512 GB SATA SSD
HP 1 TB SSD
HP 2 TB SATA SSD
HP 256 GB SATA SED Opal2 SSD
HP 240 GB Enterprise SATA SSD
HP 480 GB Enterprise SATA SSD
Storage Acceleration
16 GB Intel Optane memory (sold separately)
|
PCIe Solid State Drives
|
PCIe SSDs for HP Workstations
HP Z Turbo Drive G2 256 GB TLC PCIe SSD
HP Z Turbo Drive G2 512 GB TLC PCIe SSD
HP Z Turbo Drive G2 1 TB TLC PCIe SSD
HP Z Turbo Drive G2 2 TB TLC PCIe SSD
Intel 905p Series SSD (Optane SSD)
Intel Optane SSD 905p 280 GB AiC
Intel Optane SSD 905p 480 GB AiC
|
Removable storage
|
HP 9.5 mm Slim DVD Writer
HP 9.5 mm Slim DVD-ROM Drive
HP 9.5 mm Slim BDXL Blu-ray Writer
|
HDD Frame/carriers
|
HP DX175 Removable HDD Carrier
HP DX175 Removable HDD Frame/Carrier
|
Media card reader
|
HP SD Media Card Reader
|
NOTE:
For solid state drives or hard drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 30 GB is reserved for system recovery software.
HP Z2 Tower G4 Ports/slots
HP Z2 Tower G4 Specifications
|
Description
|
Ports
|
Front side
(1) Power button
(1) Headphone/microphone combo jack
(1) USB 3.0 Type-A charging data port
(1) USB 3.0 Type-A data port
(1) USB 3.1 Gen 2 Type-C charging data port (optional)
Back I/O ports
(1) Audio Line-In
(1) Audio Line-Out
(2) DisplayPort (DP) 1.2 outputs (from Intel UHD graphics; select models)
(1) Flexible module port output (optional flexible module required)
(2) USB 2.0 ports
(4) USB 3.0 ports
(1) Serial port (optional)
(2) PS/2 (optional)
(1) Parallel port (optional)
(1) RJ-45
(1) DC Input
Internal I/O ports
(1) USB 3.0 port
(2) USB 2.0 ports
|
Controller card
|
HP Thunderbolt 3 PCIe 3-port I/O Card
|
Rear module options
|
HP Flex IO module (VGA)
HP Flex IO module (HDMI)
HP Flex IO module (DP)
HP Flex IO module (USB-C)
HP Flex IO module (1 GbE LAN)
|
Expansion slots
|
(1) PCIe Gen3 x16 slot
(1) PCIe Gen3 x4 slot/x16 connector
(1) PCIe Gen3 x1 slot/x4 connector
(1) PCIe Gen3 x1 slot/x4 connector
(2) M.2 storage (PCIe Gen3 x4)
(1) SD Card Reader (optional)
(1) M.2 WLAN (PCIe Gen3 x1 and Intel CNVi)
|
Bays
|
(2) External 13.3 cm (5.25 in) bays
(2) Internal 8.89 cm (3.5 in) bays
|
HP Z2 Tower G4 Audio/multimedia
Feature
|
Description
|
Integrated audio
|
Conexant CX20632 5.1 HDA codec
|
HP Z2 Tower G4 Keyboard/mouse/other devices
HP Z2 Tower G4 Feature
|
Description
|
Keyboard
|
HP USB Business Slim CCID SmartCard Keyboard
HP USB Business Slim Keyboard
HP USB Premium Keyboard
HP Premium Wireless Keyboard
|
Mouse
|
HP USB Optical Mouse
HP USB Hardened Mouse
HP USB Premium Mouse
HP Premium Wireless Mouse
|
Keyboard and mouse combo
|
HP Wireless Business Slim Keyboard & Mouse
|
Other devices
|
HP Workstation Mouse Pad (Japan only)
HP Serial Port Adapter
HP Serial and PS/2 Adapter
HP Internal USB Port Kit
HP eSATA PCI Cable Kit
HP Z2 G4 TWR Front Card Guide Kit
|
HP Z2 Tower G4 Networking/communication
HP Z2 Tower G4 Feature
|
Description
|
Integrated
|
Intel I219LM PCIe GbE Controller (Intel vPro with Intel AMT 12.0)
Intel X710-DA2 2-Port 10GbE SFP and NIC
HP 10GbE SFP and SR Transceiver
Intel X550-T2 2-Port 10GbE NIC
Intel 9560 802.11a/b/g/n/ac with Bluetooth 5 M.2
Intel I350-T2 2-Port 1GbE NIC
Aquantia AQN-108 1-Port 5GbE NIC
|
HP Z2 Tower G4 Software/security
HP Z2 Tower G4 Specification
|
Description
|
BIOS
|
HP BIOSphere Gen4 (features vary)
HP DriveLock/HP Automatic DriveLock
BIOS Update via Network
Master Boot Record Security
Power On Authentication
Secure Erase (methods outlined in the National Institute of Standards and Technology Special Publication 800-88)
Absolute Persistence Module1
Pre-boot Authentication
|
Communication/connectivity
|
HP Wireless Wakeup
|
HP Value Add software
|
HP Performance Advisor (preinstalled with Windows 10 only)
HP Remote Graphics Software (RGS) 7.x
HP Hotkey Support – CMIT
HP Velocity
HP Sure Start Gen4
HP Sure Run (requires Intel 8th generation processors)
HP Sure Recover (requires Intel 8th generation processors and wired network connection)
|
Manageability
|
HP System Software Manager (SSM)
HP Client Catalog
HP BIOS Configuration Utility (BCU)
HP Driver Packs (available for download)
HP Manageability Integration Kit Gen2 (available for download)
|
Client Security software
|
Microsoft Defender
HP Client Security Manager Gen4 (requires Windows and Intel 8th generation processors)
HP Security Manager (including Credential Manager, HP Password Manager, HP Spare Key)
HP Device Access Manager
HP Power On Authentication
|
Security
|
For Windows 10, Trusted Platform Module (TPM) 2.0 (Infineon SLB9670)
RAID configurations (optional and requires a second hard drive)
Power-on password (via BIOS)
Setup password (via BIOS)
SATA port disablement (via BIOS)
Serial, USB enable/disable (via BIOS)
Integrated hood sensor
Support for chassis padlocks and cable lock devices
HP Sure Click
|
NOTE:
1Absolute agent is activated when customers activate a purchased subscription. Subscriptions can be purchased for terms ranging multiple years. Service is limited, check with Absolute for availability outside the U.S. The Absolute Recovery Guarantee is a limited warranty. Certain conditions apply. Data Delete is an optional service provided by Absolute Software. If utilized, the Recovery Guarantee is null and void. In order to use the Data Delete service, customers must first sign a Pre-Authorization Agreement and either obtain a PIN or purchase one or more RSA SecurID tokens from Absolute Software.
NOTE:
HP Cloud Recovery download tool (Cloud Recovery Client) is available under Software and Drivers section on the support page.
HP Z2 Tower G4 Power
HP Z2 Tower G4 Specifications
|
Description
|
Power supply
|
650 W Power supply
90% efficiency
Wide-ranging
Active PFC
500 W Power supply
90% efficiency
Wide-ranging
Active PFC
250 W Power supply
85% efficiency
Wide-ranging
Active PFC
|
Rated input current
|
6 A at 100 to 240 V
|
Operating voltage range
|
90 to 269 VAC
|
Operating line frequency range
|
47 to 66 Hz
|
HP Z2 Tower G4 Physical specifications
HP Z2 Tower G4 Specifications
|
Description
|
Dimensions (H x W x D)
|
Minitower orientation
356 x 169 x 435 mm (14.0 x 6.7 x 17.1 in)
Packaging
599 x 499 x 295 mm (23.5 x 19.6 x 11.6 in)
|
Weight
|
Typical weight
8.2 kg (18.07 lb)
Shipping weight
11.4 kg (25.13 lb)
|
HP Z2 Tower G4 Environmental
Feature
|
Description
|
Certifications
|
ENERGY STAR (energy-saving features available on selected configurations – Windows only)
IT ECO declaration
US Federal Energy Management Program (FEMP)
China Energy Conservation Program (CECP)
Low Halogen
|
Temperature
|
Operating
5° to 35°C (41° to 95°F)
Non-operating
-40° to 60°C (-40° to 140°F)
|
Relative humidity
|
Operating
10% to 85%, non-condensing
Non-operating
10% to 90%, non-condensing
|
Altitude (unpressurized)
|
Operating
3,048 m (10,000 ft)
Non-operating
12,192 m (15,000 ft)
|
Reviews
There are no reviews yet.
