Synology FlashStation FS3400

In stock

Synology FlashStation FS3400

CPU

CPU Model Intel Xeon D-1541
CPU Architecture 64-bit
CPU Frequency 8-Core 2.1 (base) / 2.7 (turbo) GHz
Hardware Encryption Engine (AES-NI)

Memory

System Memory 16 GB DDR4 ECC RDIMM
Memory Module Pre-installed 16 GB (16 GB x 1)
Total Memory Slots 4
Memory Expandable up to 128 GB (32 GB x 4)
Notes
  • Synology reserves the right to replace memory modules with the same or higher frequency based on the supplier’s product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
  • Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.

Storage

Drive Bays 24
Maximum Drive Bays with Expansion Unit 48 (RX1217sas) / 72 (RX2417sas)
Compatible Drive Type* (See all supported drives)
  • 2.5″ SAS HDD
  • 2.5″ SAS SSD
  • 2.5″ SATA SSD
Maximum Internal Raw Capacity 184.32 TB (7.68 TB drive x 24) (Capacity may vary by RAID types)
Maximum Raw Capacity with Expansion Units 552.96 TB (184.32 TB + 7.68 TB drive x 48) (Capacity may vary by RAID types)
Maximum Single Volume Size*
  • 200 TB (32 GB RAM required, for RAID 5 or RAID 6 groups only)
  • 108 TB
Hot Swappable Drive
Notes
  • “Compatible drive type” indicates the drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
  • The maximum raw capacity is not limited by the maximum single volume size. Synology NAS models may utilize capacities over the maximum single volume size as long as each volume created is below the limit. (Learn more)
  • Each internal volume (may consist of multiple drives) is expandble up to 108TB (with memory less than 32GB) or 200TB (with memory equal to or greater than 32GB).

External Ports

RJ-45 1GbE LAN Port 4 (with Link Aggregation / Failover support)
RJ-45 10GbE LAN Port 2 (with Link Aggregation / Failover support)
USB 3.0 Port 2
Expansion Port 1

PCIe

PCIe Expansion 1 x Gen3 x8 slot (x8 link)
Add-In-Card Support PCIe Network Interface Card (Learn more)

File System

Internal Drives
  • Btrfs
  • EXT4
External Drives
  • Btrfs
  • EXT4
  • EXT3
  • FAT
  • NTFS
  • HFS+
  • exFAT*
Notes exFAT Access is purchased separately in Package Center.

Appearance

Form Factor (RU) 2U
Size (Height x Width x Depth) 88 mm x 482 mm x 724 mm
Weight 14.9 kg
Rack Installation Support* 4-post 19″ rack (Synology Rail Kit – RKS1317)
Notes The rail kit is sold separately

Others

System Fan 80 mm x 80 mm x 4 pcs
Fan Speed Mode
  • Full-Speed Mode
  • Cool Mode
  • Quiet Mode
Easy Replacement System Fan
Power Recovery
Noise Level* 57 dB(A)
Scheduled Power On / Off
Wake on LAN / WAN
Power Supply Unit / Adapter 500 W
Redundant Power Supply
AC Input Power Voltage 100 V to 240 V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 313.84 W (Access)
125.77 W (HDD Hibernation)
British Thermal Unit 1,070.86 BTU/hr (Access)
429.15 BTU/hr (HDD Hibernation)
Notes
  • Power consumption is measured when it’s fully loaded with HGST 1.8TB HUC101818CS4204 hard drive(s).
  • Noise Level Testing Environment: Fully loaded with Toshiba 600GB AL14SEB060N hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%

Temperature

Operating Temperature 0°C to 35°C (32°F to 95°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH

Certification

  • EAC
  • VCCI
  • RCM
  • KC
  • FCC
  • CE
  • BSMI

Warranty

5 Years
Notes The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)

Environment

RoHS Compliant

Packaging Content

  • Main Unit X 1
  • Accessory Pack X 1
  • AC Power Cord X 2
  • Quick Installation Guide X 1

Optional Accessories

  • D4RD-2666-16G DDR4 ECC RDIMM*
  • D4RD-2666-32G DDR4 ECC RDIMM
  • Surveillance Device License Pack
  • Expansion Unit: RX1217sas X 2
  • Expansion Unit: RX2417sas X 2
  • Synology Ethernet Adapter E10G17-F2
  • Synology Ethernet Adapter E10G18-T1
  • Synology Ethernet Adapter E10G18-T2
  • Synology Rail Kit Sliding – RKS1317
  • VS360HD
  • VS960HD
Compare
Categories: ,

Synology FlashStation FS3400

Get the Synology FlashStation FS3400 at the best price in Kenya from Synology Kenya

Synology FlashStation FS3400

Fueling IT transformation for small and midsize businesses

The lightning speed with lower TCO

Featuring an 8-core CPU and 16GB ECC RDIMM memory, Synology FlashStation FS3400 provides more than 137,000 4K random write IOPS, meeting the needs for real-time analytics, online transaction processing, and mission-critical database services.1 With built-in 10GbE Ethernet, PCIe expansion, and the support of various SAS and SATA drives, FS3400 delivers flexible and economical all-flash server deployment on demand.

CPU

Intel® Xeon® D-1541 8 Core 2.1 GHz

Memory

16GB DDR4 ECC RDIMM, up to 128GB

Expandability

1 x PCIe 3.0 for 25/40GbE NIC’s expansion

Scalability

Up to 72 x SAS/SATA drives


Synology FlashStation FS3400 RAID F1

Due to the peculiarities of SSD and RAID technology, a common challenge lies in how to prevent all of the drives from failing at the same time because of the evenly distributed workload. RAID F1 alleviates this problem with a specially designed algorithm to unevenly distribute workload to drives, enhancing the resilience of the storage pool and ensuring your data remains safe.


Complete iSCSI and virtualization solutions

Synology iSCSI storage supports most virtualization solutions such as VMware vSphere, Microsoft Hyper-V, Citrix Xen Server, and OpenStack Cinder to enhance work efficiency. You can run and manage multiple virtual machines on Windows, Linux, or DSM using Virtual Machine Manager.


5-year warranty

As we’re committed to improving product innovation and quality, Synology guarantees a robust and reliable data management experience with a 5-year limited warranty, providing responsive technical support and hardware replacement services to maximize your return on investment.


Powered by Synology DSM

Synology High Availability

Seamless transition between clustered servers in the event of a server failure to minimize the impact on applications.

Active Backup Suite

Integrated, modern, and license-free backup & instant recovery solution for VMware, Windows, Office 365, and G Suite.

Hyper Backup

Store multiple backup versions with block-level incremental data backup and cross-version deduplication.

Synology MailPlus

Secure, reliable, and private mail server solution with an intuitive and modern mail client.

Virtual Machine Manager

Run various operating systems in isolated sandboxes. Seamlessly clone, restore and migrate virtual machines.

Synology Drive

A versatile solution for file management and synchronization.


Synology FlashStation FS3400

Synology FlashStation FS3400

  • Power button and indicator
  • Beep off button
  • Drive status indicator
  • Drive tray
  • Power port
  • PSU indicator
  • PSU fan
  • Console port
  • 1GbE RJ-45 port
  • 10GbE RJ-45 port
  • USB 3.0 port
  • PCIe expansion slot
  • Expansion port
  • Reset button
